Layer 2 Functions
Port Mirroring
VLAN
Link Aggregation
Spanning Tree Protocol
IGMP Snooping
MLD Snooping
Access Control List
QoS
Security
Management Functions
Basic Management Interfaces
TX/RX/both
Many-to-1 monitor
Port-based VLAN, up to 18
VLAN groups
IEEE 802.1Q tagged VLAN
- Up to 256 VLAN groups,
out of 4094 VLAN IDs
Protocol VLAN
Provider Bridging (VLAN
Q-in-Q) support (IEEE
802.1ad)
GVRP
Voice VLAN
IEEE 802.3ad LACP supports one 2-port trunk group; static trunk supports one 2-port
trunk group
IEEE 802.1D Spanning Tree Protocol (STP)
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
STP BPDU filtering, BPDU Guard
IPv4 IGMP snooping v1/ v2 and v3
IPv6 MLD snooping v1, v2
IPv4/IPv6 IP-based ACL
MAC-based ACL
Ingress/Egress Rate Limit per port bandwidth control
Storm Control support
− Broadcast/ Multicast /DLF (Destination Lookup Failure)/ARP/ICMP
Traffic classification
- IEEE 802.1p Qos/CoS
- TCP/UDP/DSCP/IP precedence of IPv4/IPv6 packets
Strict priority and Weighted Round Robin (WRR) CoS policies
Access Control List
− IPv4/IPv6 IP-based ACL
− MAC-based ACL
Port-MAC-IP Address Binding
− Port-MAC-IP Port Setting
− Port-MAC-IP Entry Setting
MAC Address Binding
− Static MAC
− MAC Filtering
DHCP snooping to filter distrusted DHCP messages
ARP Inspection discards ARP packets with invalid MAC address to IP address binding
IPv4 and IPv6 dual stack management
Switch management interface
- RJ45 console local management
- Web switch management
- Telnet command line interface
- SNMP v1, v2c and v3
BOOTP and DHCP for IP address assignment
System maintenance
- Firmware upgrade via HTTP
- Configuration upload/download through web interface
- Hardware-based reset button for system reset to factory default
SNTP Network Time Protocol
Link Layer Discovery Protocol (LLDP)
Event message logging to remote Syslog server
21
User's Manual of FGSW-Series
Port-based VLAN, up to 26 VLAN groups
IEEE 802.1Q tagged VLAN
- Up to 256 VLAN groups, out of 4094 VLAN IDs
Protocol VLAN
Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)
GVRP
Voice VLAN
