• Source IP Address
• Source IP Mask
• Destination IP Address
• Destination IP Mask
• Source Port
• Destination Port
• VID
• CoS
• Ethernet Port
• TCP Flag
• DSCP
• IP Protocol
• Ingress Port
• Action
Button
: press this button to take effect.
Configure the Source IP Address.
Configure the Source IP Mask and the available options are shown below:
255:255:255:255
255:255:255:240
255:255:255:0
255:255:240:0
255.255:0:0
255.0.0.0
240.0.0.0
Configure the Destination IP Address.
Configure the Destination IP Mask and the available options are shown below:
255:255:255:255
255:255:255:240
255:255:255:0
255:255:240:0
255.255:0:0
255.0.0.0
240.0.0.0
Configure the Source Port of Low and High.
Configure the Destination Port of Low and High.
Configure the VID and the available range is 1-4094.
Configure the CoS and the vailable range is 0-7.
Configure the Ethernet Type.
Configure the TCP Flag and available options are shown below:
URG/0/1
ACK/0/1
PSH/0/1
RST/0/1
SYN/0/1
FIN/0/1
Configure the DSCP and the available range is 0-63.
Configure the IP Protocol.
Select the specific port as Ingress port.
Select the action and the available options are shown below:
Drop
Type 1
Type 2
Type 3
Type 4
