The page includes the following fields:
Object
•
Port Selection
• Status
• Max. Learning
Entry
• Recovery
Learning Entry
Port Status
• Port
• State
• Max. Learning
Entry
• Recovery
Learning Entry
Buttons
: press this button to select all ports.
: press this button to clear all ports selection.
: press this button to take effect.
Description
Select specific port for Port-MAC-IP Port settings.
Configure enable or disable the Port-MAC-IP Port setting and default mode is disable.
Configure maximum number of dynamic binding groups for each port, the available
range is 1 to 3.
Configure enable or disable the automatically overrides the earliest bound group when
the number of dynamically bound groups reaches the upper limit. The default mode is
disable.
Display per port list.
Display per port current operation mode.
Display per port maximum number of Max. Learning Entry function.
Display per port current operation mode of Recovery Learning Entry function.
