Step5:
Supply power to the Managed PoE+ Switch.
Connect one end of the power cable to the Managed PoE+ Switch.
Connect the power plug of the power cable to a standard wall outlet.
When the Managed PoE+ Switch receives power, the Power LED should remain solid Green.
2.2.2 Rack Mounting
To install the Managed PoE+ Switch in a 19-inch standard rack, please follow the instructions described below.
Step1:
Place the Managed PoE+ Switch on a hard flat surface, with the front panel positioned towards the front side.
Step2:
Attach the rack-mount bracket to each side of the Managed PoE+ Switch with supplied screws attached to the package.
Step3:
Secure the brackets tightly.
Step4:
Follow the same steps to attach the second bracket to the opposite side.
Step5:
After the brackets are attached to the Managed PoE+ Switch, use suitable screws to securely attach the brackets to the
rack, as shown in
Figure
Figure 2-5: Attach Brackets to the Managed PoE+ Switch.
You must use the screws supplied with the mounting brackets. Damage caused to the parts by
using incorrect screws would invalidate the warranty.
2-6.
Figure 2-6: Mounting Managed PoE+ Switch in a Rack
30
User's Manual of FGSW-Series
