Technical Specifications

Power Specifications

Note
When you use a redundant power supply (RPS), only redundant power – not additive power –
is supported. Thus, the PoE ports load does not increase when an RPS is added.
Table 267: V300 Power Options
V300-8P-2X
V300-8T-2X
V300-8P-2T-W
V300HT-8P-2X
V300HT-8T-2X
Table 268: Power Specifications
V300-8P-2X
V300-8T-2X
V300-8P-2T-W
V300HT-8P-2X
V300HT-8T-2X
20
Minimum is defined as idle, with no ports linked. Maximum is defined as fans high, all ports 100% traffic.
DC Input: 54VDC, 4.5A max
DC Input: 12VDC, 1.5A max
The PoE PSE Budget is dynamically determined by the 802.3bt
Type 4 PD input power applied to its uplinks as follows:
• 2 x 90W = PoE ports load to 105W
• 1 x 90W = PoE ports load to 50W
• 2 x 60W = PoE ports load to 75W
• 1 x 60W = PoE ports load to 30W
• 2 x 30W = PoE ports load to 30W
• 1 x 30W = PoE ports load to 0W
DC Input: 54VDC, 4.5A max
DC Input: 12VDC, 1.5A max
Minimum 21 Heat Minimum 21
Dissipation Power
(BTU/hr) Consumption
(Watts)
25.9 7.6W
11.6 3.3W
24.57 7.2W
25.8 7.6W
16.6 4.9W
ExtremeSwitching Hardware Installation Guide 445
Power Specifications
Maximum 21 Heat Maximum 21
Dissipation Power
(BTU/hr) Consumption
(Watts)
118.2 214.6W
23.8 7.0W
82.1 129.1W
113.7 213.3W
7.4 25.2W
