Table 16: Additional Port LED Meanings for PoE Switches
Label or Type
All front panel ports 1-24
or 1-48
Table 17 describes the meanings of the two-digit stack number indicator on all X460-G2 series switches.
Table 17: X460-G2 two-digit Stack Number Indicator
Label or Type
Left digit (1)
Right digit (1 – 8)
ExtremeSwitching X465 Series Switches
The X465 series switches provide 24 or 48 Ethernet ports that can be deployed in either Enterprise LAN
or high-density, top-of-rack high-performance enterprise and aggregation applications. In addition,
some models offer either 24 or 48 PoE+ ports.
The 10/100/1000BaseT ports on the X465-24W/48T/48P/48W/24MU-24W models can operate in half-
duplex mode when operating at 10Mbps or 100Mbps. In addition, these models support IEEE 802.1AE
MACsec.
The X465 series switches include the following base models:
•
ExtremeSwitching X465-24MU Switch Ports and Slots
•
ExtremeSwitching X465-24MU-24W Switch Ports and Slots
•
ExtremeSwitching X465-24S Switch Ports and Slots
•
ExtremeSwitching X465-24W Switch Ports and Slots
•
ExtremeSwitching X465-24XE Switch Ports and Slots
•
ExtremeSwitching X465-48P Switch Ports and Slots
74 ExtremeSwitching Hardware Installation Guide
Color/State
Steady green
Steady amber
Blinking green
Blinking amber
Slow blinking amber
Alternating amber and
green
Off
Color/State
Reserved for future use
Indicates the position of this switch in the SummitStack configuration
Upper half blinking
Lower half blinking
Lit steadily
ExtremeSwitching Switches
Meaning
Link is OK; port is not powered
Link is OK; port is powered; no traffic
Link is OK and transmitting packets; port is
not powered
Link is OK and transmitting packets; port is
powered
No link, or disabled port; port is powered
Port has a power fault
Port is not powered, has no link, or is disabled
Meaning
This switch is the stack master node
This switch is the stack backup node
This switch is a standby node in the stack
on page 77
on page 78
on page 78
on page 78
on page 79
on page 79
