ExtremeSwitching X870 Series Switches

Location
LED
Partitionable
Ports 51-54,
56-59
All
Note
Each QSFP port that can be partitioned has four LEDs.
ExtremeSwitching X870 Series Switches
The X870 series switch is a 100 Gb switch suited for large datacenter applications. Front-panel Ethernet
ports can provide 100-gigabit Ethernet connectivity using installable QSFP28 and QSFP+ optical
modules. The ports can operate in 40- or 100-gigabit mode and can be partitioned into 10-, 25-, and 50-
gigabit data lanes. (See
example.)
The X870 provides latency less than 600 nanoseconds and supports cut-through switching to help
optimize high frequency trading applications as well as latency sensitive cluster computing.
Native stacking with other X870 series switches is supported using the front panel-ports.
The X870 series includes the following base models:
•
ExtremeSwitching X870-32c Switch Ports and Slots
•
ExtremeSwitching X870-96x-8c Switch Ports and Slots
X870 series switches require ExtremeXOS version 22.2.1 or later.

Partitioning X870 Switch Ports into Data Lanes

Front-panel ports on X870 series switches can be configured for either 100-gigabit or 40-gigabit mode,
and each port can be partitioned into data lanes through the use of split cables. This yields a total of up
to 128 ports.
112 ExtremeSwitching Hardware Installation Guide
Speed LED
Indication
50 Gbps
(partitioned)
51, 53
10/25Gbps
(partitioned)
40 Gbps/
100Gbps (no
partition)
Off or Not Present
Partitioning X870 Switch Ports into Data Lanes
ExtremeSwitching Switches
Color/State
Solid green (1, 3)
(2, 4 - Off)
Blinking green
Solid green (1, 2, 3,
4)
Blinking green (1, 2,
3, 4)
Solid green (1)
(2, 3, 4 - Off)
Blinking green (1)
(2, 3, 4 - Off)
Off
on page 112 for details and an
on page 114
on page 115
Description
The port has link
Port is transmitting
or receiving
The port has link
Port is transmitting
or receiving
The port has link
Port is transmitting
or receiving
No link or port
disable
