Technical Specifications
2 = Pin 9
Table 349: STK-RPS-1005PS Connector Pin Functions
Pin
1
2
3
4
5
6
7
8
9

VX-RPS-1000 Redundant Power Supply Technical Specifications

The following tables list the specifications for the model VX-RPS-1000 Redundant Power Supply.
Table 350: VX-RPS-1000 Unpackaged Dimensions
Height: 1.64 inches (4.17 cm)
Width: 5.27 inches (13.4 cm)
Length: 15.21 inches (38.6 cm)
Weight: 11.51 lb (5.22 kg)
Table 351: VX-RPS-1000 Packaged Dimensions
Height: 5.04 inches (12.8 cm)
Width: 12.57 inches (31.9 cm)
Length: 21.91 inches (55.6 cm)
Weight: 13.00 lb (5.89 kg)
Table 352: VX-RPS-1000 Power Specifications
AC input frequency range
AC input voltage range
AC input current
VX-RPS-1000 Redundant Power Supply Technical
4 = Pin 18
Function
12 V power
12 V power
12 V power
Ground
Ground
Spare pin
-55 V power
-55 V power
-55 V power return
50/60 Hz
100-120 VAC or 200-240 VAC
12 A maximum at 120 VAC, 60 Hz
6.0 A maximum at 240 VAC, 50 Hz
ExtremeSwitching Hardware Installation Guide 473
Pin
10
11
12
13
14
15
16
17
18
Specifications
Function
Power good of RPS
Power supply present
12 V current sharing
Ground
Spare pin
-55 V current sharing
-55 V power
-55 V power return
-55 V power return
