ExtremeSwitching X440-G2-12t8fx-GE4 Switch Ports
and Slots
Figure 31: ExtremeSwitching X440-G2-48t-10GE4-DC Rear Panel
1 = SFP Ports upgradeable to 10GBASE-X
2 = 1GBASE-T combination ports upgradeable to 10GBASE-T
3 = Redundant power input

ExtremeSwitching X440-G2-12t8fx-GE4 Switch Ports and Slots

The ExtremeSwitching X440-G2-12t8fx-GE4 switch ports and slots include:
•
12 front panel 10/100/1000BASE-T ports, all of which support both half-duplex and full-duplex
communication.
•
Four unpopulated front panel 1GBASE-X SFP ports.
•
Eight 100BASE-FX LC connectors.
•
Ethernet management port (10/100/1000BASE-T).
•
Serial console port implemented as an RJ45 connector used to connect a terminal and perform local
management.
•
One front panel USB 2.0 port, operational on switches running ExtremeXOS version 22.2 or later.
•
One rear redundant power supply connector.
The X440-G2 12t8fx-GE4 switch supports an operating range from 0°C to 60°C.
42 ExtremeSwitching Hardware Installation Guide
Note
The LC connectors are transceivers with an LC interface.
ExtremeSwitching Switches
4 = DC power connector panel
5 = Grounding lug
