Technical Specifications

Power Options

Table 215: Summit X670-G2 Power Options
X670-G2-48x-4q (part # 17310)
X670-G2-72x (part # 17300)
Table 216: Power Consumption
Switch Model
X670-G2-48x-4q
X670-G2-72x
Table 217: CPU, Memory
CPU/Memory
1 GHz 64-bit CPU
2 GB DDR3 ECC SDRA memory
4 GB eMMC Flash Memory
12 MB buffer, per chip
550 W AC power supply:
Part # 10925 550 W AC PS FB (front-to-back), Model #
DS550HE-3
Part # 10927 550 W AC PS BF (back-to-front), Model #
DS550HE-3-02
100-240 V, 50/60 Hz, 2.25 A max per PS
550 W DC power supply:
Part # 10926 550 W DC PS FB (front-to-back), Model #
DS550DC-3
Part # 10928 550 W DC PS BF (back-to-front), Model #
DS550DC-3-003
-48 VDC, 5.75 A max per PS
550 W AC power supply:
Part # 10925 550 W AC PS FB (front-to-back), Model #
DS550HE-3
Part # 10927 550 W AC PS BF (back-to-front), Model #
DS550HE-3-02
100-240 V, 50/60 Hz, 2.75 A max per PS
550 W DC power supply:
Part # 10926 550 W DC PS FB (front-to-back), Model #
DS550DC-3
Part # 10928 550 W DC PS BF (back-to-front), Model #
DS550DC-3-003
-48 VDC, 6.75 A max per PS
Minimum Heat Minimum Power
Dissipation Consumption
325 BTU/hr 95 W
325 BTU/hr 95 W
Maximum Heat
Dissipation
768 BTU/hr
939 BTU/hr
ExtremeSwitching Hardware Installation Guide 427
Power Options
Maximum Power
Consumption
225 W
275 W
