Install a V300 Virtual Port Extender on a Wall
•
M4 #2 Phillips screwdriver (magnetic srewdriver recommended) for non-PoE models
Note
The mounting surface, item, and hardware must be able to support the extender in all
environmental conditions. The mounting surface must also be flat.
Typical installation for the V300-8P-2T-W model include wall or table installations, in addition to VESA
mounting.
There are several orientations for installation on a wall. To install the V300-8P-2T-W model on a wall:
1. Attach the short brackets to both sides of the extender
The orientation for wall mounting should be front panel facing down.
Two short brackets attached to the extender by 4 wood screws and 4 anchors, provided in the
accessory kit.
