750 W Power Supplies Technical Specifications

Table 304: Power Specifications (continued)
Power cord wall plug
Efficiency
Table 305: Environmental Specifications
Operating temperature
Storage temperature
Operating humidity
Operational shock
750 W Power Supplies Technical Specifications
The Summit 750 W AC power supply (part no. 10931) is available for use with ExtremeSwitching
X620-16p switches. It is compatible with the EPS-C2 power supply.
The Summit 750 W AC power supply is used in the EPS-C2 external power system.
Table 306: Physical Specifications
Dimensions
Weight
Table 307: Power Specifications
Voltage input range
Nominal input ratings
Nominal input current at full loads
Line frequency range
Maximum inrush current
Output
Power supply input socket
Power cord input plug
Power cord wall plug
458 ExtremeSwitching Hardware Installation Guide
Refer to Power Cord Requirements for AC-Powered Switches
and AC Power Supplies on page 475
Minimum efficiency: 88% at maximum power output
-10°C to 50°C (normal operation)
-40°C to 70°C
93% relative humidity, non-condensing at 30C
30 m/s 2 (3 G)
Height: 1.57 inches (4.0 cm)
Width: 3.15 inches (8.0 cm)
Depth: 9.5 inches (24.1 cm)
2.25 lb (1 kg)
85 to 264 V
100 to 240 V , 50 to 60 Hz, 10 A
10 A at 90 V (low-line)
3.7 A at 230 V (high-line)
47 to 63 Hz
35 A
12 V , 25 A max, 300 Watts
55 V , 8.18 A max, 450 Watts
3.3 V , 3.03 A max, 10 Watts
IEC 320 C14
IEC 320 C13
Refer to Power Cord Requirements for AC-Powered Switches
and AC Power Supplies on page 475.
