Power Supplies for Use with Your Switch
Table 38: External Power Supplies for X440-G2 Series Switches (continued)
Switch Model
X440-G2-24t-10GE4-DC 150 W Non-PoE Redundant Power Supply
X440-G2-48t-10GE4-DC 150 W Non-PoE Redundant Power Supply
X440-G2-12t8fx-GE4
X440-G2-24fx-GE4
X440-G2-24t-GE4
Table 39: External Power Supplies for X450-G2 Series Switches
Switch Model
X450-G2-24t-GE4
X450-G2-24t-10GE4
Compatible External Power Supply
150 W RPS-150XT External Power Supply Unit
500 W PoE+ Redundant Power Supply Unit
750 W Power Supply with EPS-C2 chassis
150 W RPS-150XT External Power Supply Unit
500 W PoE+ Redundant Power Supply Unit
750 W Power Supply with EPS-C2 chassis
150 W Non-PoE Redundant Power Supply
150 W RPS-150XT External Power Supply Unit
500 W PoE+ Redundant Power Supply Unit
750 W Power Supply with EPS-C2 chassis
150 W Non-PoE Redundant Power Supply
150 W RPS-150XT External Power Supply Unit
500 W PoE+ Redundant Power Supply Unit
750 W Power Supply with EPS-C2 chassis
150 W Non-PoE Redundant Power Supply
150 W RPS-150XT External Power Supply Unit
500 W PoE+ Redundant Power Supply Unit
750 W Power Supply with EPS-C2 chassis
Compatible External Power Supply
150 W Non-PoE redundant power supply
500 W PoE+ Redundant Power Supply Unit
750 W Power Supply with EPS-C2 chassis
150 W Non-PoE redundant power supply
500 W PoE+ Redundant Power Supply Unit
750 W Power Supply with EPS-C2 chassis
ExtremeSwitching Hardware Installation Guide
External Power Supplies
Model: Part Number
STK-RPS-150PS
RPS-150XT
RPS-500p: 10923
750 W AC
PSU: 10931
EPS-C2: 10936
STK-RPS-150PS
RPS-150XT
RPS-500p: 10923
750 W AC
PSU: 10931
EPS-C2: 10936
STK-RPS-150PS
RPS-150XT
RPS-500p: 10923
750 W AC
PSU: 10931
EPS-C2: 10936
STK-RPS-150PS
RPS-150XT
RPS-500p: 10923
750 W AC
PSU: 10931
EPS-C2: 10936
STK-RPS-150PS
RPS-150XT
RPS-500p: 10923
750 W AC
PSU: 10931
EPS-C2: 10936
Model: Part Number
STK-RPS-150PS
RPS-500p: 10923
750 W AC PSU: 10931
EPS-C2: 10936
STK-RPS-150PS
RPS-500p: 10923
750 W AC PSU: 10931
EPS-C2: 10936
