Technical Specifications
Table 295: Environmental Specifications (continued)
Operating humidity
Operational shock

Summit 350 W Power Supplies Technical Specifications

The following Summit 350 W power supplies are available for use in X460-G2 series PoE switches:
•
Summit 350 W AC power supply: front-to-back airflow (part no. 10953)
•
Summit 350 W AC power supply: back-to-front airflow (part no. 10954)
Model 10953 (front-to-back airflow) is also compatible with the ExtremeSwitching X465-24S,
X465-24XE, and X465-48T switch models.

Summit 350 W AC Power Supply (10953, 10954)

Table 296: Physical Specifications
Dimensions
Weight
Table 297: Power Specifications
Voltage input range
Nominal input ratings
Maximum inrush current
Output
Power supply input socket and cord
Power cord wall plug
Efficiency
Table 298: Environmental Specifications
Operating temperature
Storage temperature
Operating humidity
Operational shock
Summit 350 W Power Supplies Technical Specifications
20% to 90% relative humidity, non-condensing
30 m/s 2 (3 G)
Height: 1.57 inches (4.0 cm)
Width: 3.25 inches (8.3 cm)
Length: 10.22 inches (26.0 cm)
2.55 lb (1.12 kg)
100-127/200-240 47 to 63Hz
12.5 A max at 115VAC and 6A max at 230VAC at Full 350 W load
45A at Max 264 VAC at 25C with cold start
54 V, 13.2 A max, 350 W
IEC/EN 60320-1/C16 AC input receptacles
Refer to Power Cord Requirements for AC-Powered Switches
and AC Power Supplies on page 475
Minimum efficiency: 88% at maximum power output
-10°C to 50°C (normal operation)
-40°C to 70°C
93% relative humidity, non-condensing at 30C
30 m/s 2 (3 G)
