17300 Summit X670-G2-72x
17300T SummitX670-G2-72x
Summit X670-G2 Series Switches
Installation Note
Pre-installation Requirements
Before you install the Summit X670-G2 series switch, read the information in
page
2.
The following items are provide with the Summit X670 series switch:
Mounting brackets
●
Eight M3 screws to secure the mounting brackets to the switch
●
To install the switch in a rack, you need the following additional tools and equipment:
Four rack mounting screws to match your equipment rack
●
Screwdriver to fit the rack mounting screws
●
AC power cord that is suitable for the current rating of this product (See
●
Supply Cords" on page
Required Tools
The following items are provided with the Summit X670-G2 series switch:
Two rack mounting brackets adaptable for either a front-mount or mid-mount installation
●
Twelve screws for attaching the brackets to the switch enclosure
●
For DC models, spade terminal and M4 screw with captive washer for grounding the switch
●
You need the following additional tools and materials to install the switch in a rack:
#1 Phillips screwdriver
●
Four rack mounting screws to match your equipment rack
●
Screwdriver to fit the rack mounting screws
●
#14 AWG stranded copper cable for grounding the switch (DC powered models)
●
ESD-preventive wrist strap for installing optional ports at the back of the switch
●
Part Number: 120845-00 Rev. 01
4.
"Safety Information" on
"Selecting AC Power
1

Advertisement

Table of Contents
loading

Related Manuals for Extreme Networks Summit X670-G2 Series

Summary of Contents for Extreme Networks Summit X670-G2 Series

  • Page 1 17300 Summit X670-G2-72x 17300T SummitX670-G2-72x Summit X670-G2 Series Switches Installation Note Pre-installation Requirements Before you install the Summit X670-G2 series switch, read the information in “Safety Information” on page The following items are provide with the Summit X670 series switch: Mounting brackets ●...

  • Page 2: Installing The Switch

    6 Connect the other end of the power cable to an AC power socket. Safety Information WARNING! Read the safety information in this section before you install Extreme Networks products. Failure to follow this safety information can lead to personal injury or damage to the equipment. Summit X670-G2 Series Switches Installation Note...

  • Page 3: Maintenance Safety

    Failure to follow these instructions may damage the equipment or violate required safety and EMC regulations. The chassis cover should be removed only by Extreme Networks personnel. This system contains no ● customer-serviceable components. Repairs to the system must be performed by an Extreme Networks factory service technician.
  • Page 4 Selecting AC Power Supply Cords Extreme Networks does not include AC power input cords in the product box. To purchase a power cord for your product and for your specific country, contact your local Extreme Networks Channel Account Manager or Sales Manager, or purchase a cord from your local supplier.
  • Page 5 ● momentary increases or decreases in electrical power. Summit X670-G2 series switches do not have switches for turning the unit on and off. Remove the ● wall plug from the electrical outlet to disconnect the power from a Summit X670-G2 series switch.

  • Page 6: Battery Replacement And Disposal

    Batteries included with Extreme products are encapsulated and must be replaced only by qualified Extreme Service personnel. Contact your Extreme Networks Service personnel for product replacement. Do not attempt to replace the battery. If these instructions are disregarded and replacement of these batteries is attempted, the following guidelines must be followed to avoid danger of explosion: Replace with the same or equivalent battery type as recommended by the battery manufacturer.
  • Page 7 Un disjoncteurListed dédié évalué à 20A doit être utilisée pour chaque connexion d'alimentation . WARNING! Extreme Networks power supplies do not have switches for turning the unit on and off. Disconnect all power cords to remove power from the device. Make sure that these connections are easily accessible.
  • Page 8 Canada Warnings WARNING! This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. Summit X670-G2 Series Switches Installation Note...

  • Page 9: Überlegungen Vor Der Installation

    Versichern Sie sich, dass Ihre Netzteile den Gleichstrom- bzw. Wechselstrombedarf aller ● Netzwerkgeräte decken können. Racks für Extreme Networks-Geräte müssen fest am Boden verankert werden. Bei nicht ● vorschriftsmäßiger Fixierung des Racks besteht die Gefahr, dass das Rack bei Wartungsarbeiten umkippt.

  • Page 10: Allgemeine Sicherheitshinweise

    ● Netzteil, Modul oder andere Komponenten eigenmächtig zu reparieren. Senden Sie im Falle einer Störung das defekte Teil zur Reparatur oder zum Austausch an Extreme Networks ein, sofern ein Extreme Networks-Vertreter nicht etwas anderes angibt. Um das System spannungslos zu machen, müssen Sie alle Netzkabel aus den Netzsteckdosen ziehen.

  • Page 11: Kabelverlegung Für Lan-Systeme

    Zugentlastungsvorrichtungen. Kabelverlegung für LAN-Systeme Extreme Networks-Geräte erfüllen die Anforderungen für Geräte für LAN-Systeme. LAN-Systeme sind für gebäudeinterne Installationen konzipiert, das heißt, die Kabel zwischen den einzelnen Einheiten müssen im gleichen Gebäude verlaufen, in dem auch die Geräte untergebracht. Hiervon ausgenommen sind nur die unten aufgeführten Bedingungen.

  • Page 12: Installation Der Netzteile Und Netzanschluss

    ● vom Nutzer zu warten sind. Senden Sie im Falle einer Störung das defekte Netzteil zur Reparatur oder zum Austausch an Extreme Networks ein. Fassen Sie nicht mit der Hand in einen offenen Netzteileinschub, wenn das Netzteil entfernt wurde. ●...

  • Page 13: Auswahl Der Netzkabel

    Bereich kann beispielsweise nur mithilfe eines Spezialwerkzeugs, Schloss und Schlüssel oder einer anderen Sicherheitsvorrichtung geöffnet werden. NOTIZ Da die Gebäudevorschriften in aller Welt unterschiedlich sind, empfiehlt Extreme Networks dringend, sich bezüglich der korrekten Erdung und Spannungsverteilung für Ihre Installation in Ihrem Land an einen Elektrofachbetrieb zu wenden.

  • Page 14: Wechseln Und Entsorgen Der Batterie

    Die Batterien in Extreme Produkten sind gekapselt und dürfen nur durch qualifiziertes Extreme-Wartungspersonal ausgewechselt werden. Wenden Sie sich für den Austausch eines Produktes an das Wartungspersonal von Extreme Networks. Versuchen Sie nicht, die Batterie selbst auszuwechseln. Bei einer Missachtung dieser Anweisungen und dem Versuch, die Batterien eigenmächtig zu wechseln, müssen folgende Richtlinien eingehalten werden, um eine mögliche...

  • Page 15: Conformity Statements For Emc Class A

    Conformity Statements for EMC Class A Konformität von GBIC, SFP (Mini-GBIC), QSFP+, XENPAK und XFP Steckbare optische Module von Extreme Networks und direkt angeschlossene Kabel erfüllen folgende gesetzliche Vorschriften: Laserprodukt der Klasse 1 oder Klasse 1M ● EN60825-1:2007 2. Ausgabe oder später, Europäische Norm ●...

  • Page 16: Fiber Optic Ports And Optical Safety

    Korea EMC Statement Fiber Optic Ports and Optical Safety The following safety warnings apply to all optical devices used in Extreme Networks equipment that are removable or directly installed in an I/O module or chassis system. Such devices include but are not limited to gigabit interface converters (GBICs), small form factor pluggable (SFP) modules (or mini-GBICs), QSFP+ modules, XENPAK transceivers, and XFP laser optic modules.
  • Page 17 Never alter, modify, or change an optical device in any way other than suggested in this ● document. GBIC, SFP (Mini-GBIC), QSFP+, XENPAK, and XFP Regulatory Compliance Extreme Networks pluggable optical modules and direct-attach cables meet the following regulatory requirements: Class 1 or Class 1M Laser Product ● EN60825-1:2007 2nd Ed. or later, European standard ●...
  • Page 18 Dual PSU power slot with 550W AC Power Supplies and Front-to-Back or Back-to-Front airflow. ● Five fan slots for fan modules with Front-to-Back or Back-to-Front airflow. ● Ethernet management port 1 x 10/100/1000BASE-T. ● Summit X670-G2 Series Switches Installation Note...
  • Page 19 X670-G2 Series Switches X670-G2 Series Switches The Summit X670-G2 series includes the following switches: Summit X670-G2-48x-4q ● Summit X670-G2-72x ● Table 1: Summit X670-G2 Series Switch Technical Specifications Physical Dimensions Summit X670-G2-48x-4q switch Height: 1.73 inches (4.4 cm) Width: 18.7 inches (47.5 cm) Depth: 10.0 inches (25.4 cm)
  • Page 20 Unified Access Architecture, Unified Access RF Manager, UniStack, XNV, the Extreme Networks logo, the Alpine logo, the BlackDiamond logo, the Extreme Turbodrive logo, the Summit logos, and the Powered by ExtremeXOS logo are trademarks or registered trademarks of Extreme Networks, Inc. or its subsidiaries in the United States and/or other countries.
