ExtremeSwitching Switches
Table 36: X695 System LEDs (continued)
LED indication
Fantray 1 (Back)
Fantray 2 (Back)
Fantray 3 (Back)
Fantray 4 (Back)
Fantray 5 (Back)
Fantray 6 (Back)
FAN
(front faceplate)
The X695 front panel port LEDs behave as follows:
Location
LED
Port 1-48 (10G
bps)
LED Port
49-62.
Ports 49, 50,
55, 60-62 are
not
partitionable
Color
Green
Red
Green
Amber
Speed LED
Indication
10G/1Gbps Link/
Act/
Speed
40Gbps/
100Gpbs
(no partition)
ExtremeSwitching X695 Switch LEDs
Behavior
Solid
Solid
Solid
Blinking
Solid
Color/State
Solid green
Blinking green
Solid green (1)
(2, 3, 4 - Off)
Blinking green (1)
(2, 3, 4 - Off)
ExtremeSwitching Hardware Installation Guide
Description
All diagnostics pass
and the module is
operational
Failure, module not
receiving power, not
present
All modules are
operational
Failure in at least one
of the modules or
POST in progress if
SYS is solid amber
POST in progress if
SYS is solid amber
Description
The port has link
Port is transmitting
or receiving
The port has link
Port is transmitting
and/or receiving
