Power Options - Extreme Networks ExtremeSwitching X435 Series Hardware Installation Manual

Technical Specifications
Table 109: X435-24P-4S Fan Speed and Power Consumption
Fan Speed
Full
Low
* Some units are equipped with (1) fan module, while others are equipped with 2. Total fan power is
equal to the number of installed fan modules multiplied by the fan power for each module.

Power Options

Table 110: X435 Power Supply Options
Switch Model
X435-8T-4S switch
X435-8P-4S switch
X435-8P-2T-W switch
X435-24T-4S switch
X435-24P-4S switch
Table 111: X435 Power Consumption
Switch Model
X435-8T-4S switch
X435-8P-4S switch
X435-8P-2T-W switch
X435-24T-4S switch
X435-24P-4S switch
Fan Module RPM (typical)
Inlet Fan Outlet Fan
16,000 (typ) 13,500 (typ)
3,200 (typ) 2,800 (typ)
Nominal input ratings
100 to 240 V , 50-60 Hz, 0.7 A
100 to 240 V , 50-60 Hz, 3 A
802.3bt PD input power 46-57VDC 1.8AX2:
• PoE ports load to 0W, 25W, or 45W for 1 input
• PoE ports load to 25W, 65W, or 100W for 2 inputs
100 to 240 V , 50-60 Hz, 0.7 A
100 to 240 V , 50-60 Hz, 6 A
Minimum Heat
Dissipation
(BTU/hr)
257
326
236
Power
Typical
15.8W per module*
Minimum Power Maximum Heat
Consumption Dissipation
(W) (BTU/hr)
75
96
61
ExtremeSwitching Hardware Installation Guide
Power Options
Maximum Power
Consumption
(W)
963 1722
1614 3941
1110 2485
381
