Install a 300 W Internal DC Power Supply
2. Prepare the power cables and ground cable by attaching the provided connection lugs to the cables.
See
Preparing the Cables for a 300 W DC Power Supply
3. Insert the power supply into the switch.
See
Installing a 300 W DC Power Supply
4. Connect the ground wire.
See
Connecting the Ground Wire to a 300 W DC Power Supply
5. Connect the power supply to the DC source voltage.
See
Connecting a 300 W DC Power Supply to the Source Voltage
6. Energize the DC circuit.
Required Tools and Materials for Installing a 300 W DC Power Supply
You need the following tools and materials to install or remove a 300 W DC power supply.
•
Two spade terminals #8, M4 stud size, 16-14 AWG (1.25 to 2mm) wire size (Tyco part number 325199
or equivalent) for connecting the input power cables
•
One ring terminal #8, M4 stud size, 16-14 AWG (1.25 to 2mm) wire size (Tyco part number 1-51864 or
equivalent) and screw with captive lock washer for connecting the ground wire (both provided)
•
#14 AWG copper cable for grounding the power supply and connecting the power supply to the DC
power source. (DC power and grounding cables are not included with the power supply.)
Recommended insulation colors are:
◦
Red for the –48 V connection (–)
◦
Black for the –48 V RTN connection (+)
◦
Green or green with yellow stripe for the ground connection
•
Connection hardware appropriate to the installation site:
◦
Hardware for connecting the power wires to the DC source
◦
Hardware for connecting the ground wire to the site grounding point
•
Stripping tool
•
Crimping tool for attaching the lug to the ground wire
•
#2 Phillips screwdriver
•
Torque screwdriver and wrench or torque driver with attachments for tightening screws and nuts
•
ESD-preventive wrist strap
•
Thermal protective gloves (required for removal of a power supply)
Connection lugs for power and ground and a screw for connecting the ground wire are shipped with the
power supply.
Preparing the Cables for a 300 W DC Power Supply
You need a crimping tool to attach the terminals to the power and ground cables.
To prepare the cable wires, follow these steps:
1. On each cable wire, strip 6 mm (0.25 inch) of insulation from one end.
