ExtremeSwitching X450-G2 Series Switch LEDs

3
MGT FAN P1 P2 S1 S2
1
CLK ACT LINK
STACK NO. CONSOLE
1 2
Figure 52: X450-G2-48p-10GE4 Front Panel
1 = Stack number indicator
2 = Console port/Ethernet management port
3 = USB port
1
SummitStack-V84
Figure 53: X450-G2-48p-10GE4 Rear Panel
1 = 21 Gb stacking ports (QSFP+)
2 = Grounding screw
ExtremeSwitching X450-G2 Series Switch LEDs
The following sections describe the meanings of the LEDs on X450-G2 series switches.
Table 12: X450-G2 Front Panel LEDs
Label or Type
M (Management)
S1, S2 (Stack
Management)
56 ExtremeSwitching Hardware Installation Guide
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
Summit
2
Color/State
Slow blinking green (1 Hz)
Fast blinking green (2 Hz)
Steady green
Blinking amber
Off
Steady green
Blinking green
4
20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37
™ X450-G2-48p-10GE4
4 = PoE+ 10/100/1000BASE-T ports
5 = SFP+ 10GBASE-X ports
3
3 = Front-to-back fan module slot
4 = PoE+ power supply bays
Meaning
Normal operation
Power-on self test (POST) in progress
or
Switch diagnostics are running
POST passed: system is booting image
System is disabled: POST failed or system
overheated
No external power is attached
Link OK on the indicated stacking port
Activity on the indicated stacking port
