Installing Expansion Modules
See the following sections for installation instructions.
1. Attaching the adapter to the rack so that it is oriented horizontally.
See

Installing an LRM/MACsec Adapter Horizontally

2. Attaching up to five adapters to the five-slot mounting bracket (part no. 10966).
See Installing LRM/MACsec Adapters in the Five-Slot Bracket
3. Attaching the adapter to the rack so that it is oriented vertically.
See Installing an LRM/MACsec Adapter Vertically
Figure 258: Three Ways to Install the LRM/MAC Adapter
Note
The LRM/MACsec Adapter is hot-swappable.
Installing an LRM/MACsec Adapter Horizontally
Refer to Installing an LRM/MACsec Adapter
Adapter.
Installing an LRM/MACsec Adapter Horizontally
on page 317.
on page 318.
on page 319.
on page 316 for installation options for the LRM/MACsec
ExtremeSwitching Hardware Installation Guide 317
