Installing External Power Supplies
When installing an EPS-C2 chassis at the same time as a switch, install the components in the following
order:
1. Install the switch into a rack.
2. Install the EPS-C2 chassis into a rack.
3. Install power supplies into the EPS-C2 chassis.
4. Attach the redundant power cable from the EPS-C2 chassis to the switch.
5. Attach an AC power cord to the switch's internal power supply.
Then plug it into an AC power source.
6. Connect AC power cords to the internal power supplies of the EPS-C2 chassis.
Then plug each cord into an AC power source.
The following sections describe the specific steps for installing the EPS-C2 chassis.
Note
An AC power cord is not provided with the Summit 750 W AC power supply. See
Power Supply Cords

Installing an EPS-C2 Chassis

To mount the EPS-C2 chassis in a 19-inch rack, follow these steps:
1. Place the EPS-C2 chassis upright on a secure work surface.
2. Remove the mounting bracket kit from the packaging.
3. Attach the mounting brackets as follows:
a. Place a mounting bracket over the mounting holes on one side of the EPS-C2 (see
Warning
Be sure to attach power to components in the order listed in this section. If you attach
power out of the order listed, you can damage your equipment.
on page 483 for information about selecting a power cord.
ExtremeSwitching Hardware Installation Guide 265
Installing an EPS-C2 Chassis
Selecting
Figure 206).
