Power Supplies for Use with Your Switch
In a redundant power configuration, both power supplies are fully fault-tolerant and load-sharing. You
can remove one power supply without interrupting switch operation.
Specific switch series and models are compatible with different power supply models, as shown in the
following table:
Table 47: Replaceable Internal Power Supply Compatibility
Hardware Model
X450-G2 switch (PoE models)
X460-G2 switch (non-PoE
models)
X460-G2 switch (PoE models)
X465 Switch (non-PoE model)
X465 Switch (PoE models)
X590 switches (all models)
X620-16t switch
X620-16x switch
X670-G2 switch
X690 switches (all models)
X695 switch
X870 switches (all models)
EPS-C2 RPS
Note
AC power input cords are not provided with an AC power supply. You can order an
appropriate cord from Extreme Networks or from your local supplier. The power cord must
meet the requirements listed in
Power Supplies
AC Power Supplies: Part No.
715 W AC-FB: 10951
1100 W AC-FB: 10941
300 W AC-FB: 10930A
300 W AC-BF: 10943
350 W AC-FB: 10953
350 W AC-BF: 10954
715 W AC-FB: 10951
715 W AC-BF: 10952
1100 W AC-FB: 10941
1100 W AC-BF: 10942
350 W AC-FB: 10953
715 W AC-FB: 10951
1100 W AC-FB: 10941
ExtremeSwitching 2000 W AC
Power Supply on page 138
-FB: XN-ACPWR-2000W-F
770 W AC-FB: 10960
770 W AC-BF: 10961
300 W AC-FB: 10930A
300 W AC-BF: 10943
550 W AC-FB: 10925
550 W AC-BF: 10927
770 W AC-FB: 10960
770 W AC-BF: 10961
750 W AC and DC Power
Supplies on page 135
-FB:XN-ACPWR-750W-F
750 W AC and DC Power
Supplies on page 135
-FB:XN-ACPWR-750W-R
770 W AC-FB: 10960
770 W AC-BF: 10961
750 W AC: 10931
Power Cord Requirements for AC-Powered Switches and AC
on page 475.
ExtremeSwitching Hardware Installation Guide
Replaceable Internal Power Supplies
DC Power Supplies: Part No.
300 W DC-FB: 10933
300 W DC-BF: 10944
1100 W DC-FB: 10962
1100 W DC-BF: 10963
300 W DC-FB: 10933
300 W DC-BF: 10944
550 W DC-FB: 10926
550 W DC-BF: 10928
1100 W DC-FB: 10962
1100 W DC-BF: 10963
750 W AC and DC Power
Supplies on page 135
-BF:XN-DCPWR-750W-F
750 W AC and DC Power
Supplies on page 135
-BF:XN-DCPWR-750W-R
1100 W DC-FB: 10962
1100 W DC-BF: 10963
