ExtremeSwitching X460-G2 Series Switch LEDs

•
Rear dual PSU power slots with front-to-back or back-to-front airflow
•
One rear slot for fan module with front-to-back or back-to-front airflow
Figure 78: X460-G2-16mp-32p-10GE4 Front Panel
1 = USB port
2 = Stack number indicator
3 = Console port/Ethernet management port
Figure 79: X460-G2-16mp-32p-10GE4 Rear Panel
1 = TM-CLK (clock) slot cover
2 = VIM slot cover
3 = Fan module slot
ExtremeSwitching X460-G2 Series Switch LEDs
Table 15 describes the meanings of the front-panel LEDs on all X460-G2 series switches.
Table 15: X460-G2 Front Panel LEDs
Label or Type
M (Management)
72 ExtremeSwitching Hardware Installation Guide
4 = Blank power supply cover
5 = Power supply slot
Color/State
Slow blinking green (1 Hz)
Fast blinking green (2 Hz)
Steady green
Blinking amber
Off
ExtremeSwitching Switches
4 = PoE+ 100/1000/2.5G BASE-T ports
5 = PoE+ 10/100/1000BASE-T ports
6 = SFP+ 10GBASE-X ports
Meaning
Normal operation
Power-on self test (POST) in progress
or
Switch diagnostics are running
POST passed; system is booting image
System is disabled: POST failed or system
overheated
No external power is attached
