Technical Specifications
Table 313: Power Specifications (AC Power Supplies) (continued)
Power cord input plug
Power cord wall plug
Power supply cord gauge
Efficiency
Table 314: Power Specifications (DC Power Supplies)
Nominal input
DC Voltage input range
Inrush Current
Maximum wire size
DC Output
Power (W)
Table 315: Environmental Specifications (All Power Supply Units)
Operating temperature
Storage temperature
Operating humidity
Operational shock

Summit 770 W Power Supplies Technical Specifications

The following Summit 770 W power supplies are available for use in ExtremeSwitching X690 and X870
series switches.
•
Summit 770 W AC power supply: front-to-back airflow (part no. 10960)
Summit 770 W Power Supplies Technical Specifications
IEC 320 C13
Refer to Power Cord Requirements for AC-Powered Switches
and AC Power Supplies on page 475.
18 AWG (0.75 mm 2 ) up to 6 feet or 2 meters
or
16 AWG (1.0 mm 2 ) over 6 feet
Low Line: 88% at 50% load and 86% at 100% load
High Line: 90% at 50% and 100% loads
-48 to -60 VDC, 20.4 A
-35 to -75 V
21 A peak
14 AWG (1.5 mm2 copper stranded).
+12.2VDC, 61.5A; +12Vaux, 2.5A
750 W
0°C to 55°C (normal operation)
-40°C to 70°C
20% to 90% relative humidity, non-condensing
30 m/s 2 (3 G)
ExtremeSwitching Hardware Installation Guide 461
