Replacing a Versatile Interface Module, Solid-state Drive,
or Clock Module in an X460-G2 Series or X465 Series
Switch
To replace a Half-Duplex to Full-Duplex Converter or remove it from service, follow these steps:
1. Disconnect the half-duplex ports (HD1 - HD4) from your half-duplex devices.
2. Disconnect the full-duplex ports (FD1 - FD4) from the switch.
3. Disconnect the converter to its power adapter.
a. Disconnect the power adapter from its AC power source.
b. Disconnect the DC power cable from the power adapter and from the DC input socket on the
side of the converter.
c. Remove the grounding wire from the converter.
4. If the converter is attached to a 3-slot modular shelf, loosen the cable ties and remove it from the
shelf.
5. Optionally, install a new converter using the instructions in
Converter
Replacing a Versatile Interface Module, Solid-state Drive, or Clock
Module in an X460-G2 Series or X465 Series Switch
This section describes how to replace versatile interface modules (VIMs) or a clock module in the rear
slot of an X460-G2 switch, or VIM5 in the front and SSD in the rear slot of an X465 switch.
Note
Clock module ports are output ports; clock module ports are not to be used as input ports.
You need the following tools and materials to install a VIM or clock module:
•
ESD-preventive wrist strap
•
#2 Phillips screwdriver
The replacement procedure is the same for all X460-G2 VIMs and clock modules, and all X465 VIM5s
and SSDs, with the exception that the VIMs and SSDs use slotted retaining screws and the clock module
uses Phillips retaining screws.
To replace a VIM, SSD, or clock module:
1. Attach an ESD-preventive wrist strap to your wrist and connect the metal end to an appropriate
ground point on the rack.
2. Disconnect the switch power.
3. Remove the existing VIM, SSD, or clock module:
a. Remove the retaining screws holding the existing module in place.
b. Save the retaining screws to secure the new module in the switch.
c. Pull the old module out of the module slot.
4. Remove the new VIM, SSD, or clock module from its anti-static packaging.
5. Install the VIM, SSD, or clock module in the switch:
a. Carefully slide the module into the switch.
372 ExtremeSwitching Hardware Installation Guide
on page 320.
Caution
VIMs, SSDs, and clock modules are not hot-swappable. Disconnect power to the switch
before removing an installed VIM, SSD, or clock module or installing a new one.
Removing and Replacing Expansion Modules
Installing a Half-Duplex to Full-Duplex
