Expansion Modules
Figure 135: VIM5-2Q Versatile Interface Module
Table 63: Port Numbers for Ports on the VIM5-2Q Module
ExtremeSwitching X465
Port Number for 24-port Models
25, 29 in 1x40 mode
25-28, 29-32 in 4x10 mode
VIM5-2Y Versatile Interface Module
The VIM5-2Y versatile interface module provides two 25-GbE (SFP28) ports.
The VIM5-2Y can be configured to provide two 10GbE ports using the port partitioning CLI. For details
about the configure ports partition command, see the
Reference
For information about the supported optical modules, refer to the most recent version of the
Hardware/Software Compatibility and Recommendation
Guide.
VIM5-2Y Versatile Interface Module
ExtremeSwitching X465
Port Number for 48-port Models
49, 53 in 1x40 mode
49-52, 53-56 in 4x10 mode
ExtremeXOS 30.7 Command
Matrices.
ExtremeSwitching Hardware Installation Guide
Extreme
153
