Technical Specifications

Fan and Acoustic Noise

Table 187: Fan and Acoustic Noise
Switch Model
X590-24t-1q-2c (part
no. 16791)
FB airflow
X590-24t-1q-2c (part
no. 16791)
BF airflow
X590-24x-1q-2c (part
no. 16790)
FB airflow
X590-24x-1q-2c (part
no. 16790)
BF airflow

Power Options

Table 188: X590 Power Options
X590-24t-1q-2c (part # 16791)
X590-24x-1q-2c (part # 16790)
Table 189: Power Specifications
Switch Model
X590-24t-1q-2c
X590-24x-1q-2c
Bystander Sound Pressure (at 25°C)
54.7 db(A) up to 25°C
61.9 db(A) up to 35°C
79.4 db(A) at 45°C (max)
55.5 db(A) up to 25°C
62.6 db(A) up to 35°C
79.7 db(A) at 45°C (max)
55.6 db(A) up to 30°C
57.8 db(A) up to 40°C
79.8 db(A) at 45°C (max)
55.8 db(A) up to 30°C
57.9 db(A) up to 40°C
79.1 db(A) at 45°C (max)
770 W AC power supply:
Part # 10960 770 W AC PS FB (front-back)
Part # 10961 770 W AC PS FB (back-front)
AC Input: 100-240 VAC, 50/60 Hz
PSU Input Socket: IEC 320 C14
Power cord input plug: IEC 320 C13
1100 W DC power supply:
Part # 10962 1100 W DC PS FB (front-back)
Part # 10963 1100 W DC PS FB (back-front)
DC Input: -48 VDC
AC Input: 100-127 VAC, 2.5 A max. per PSU, 50/60 Hz
AC Input: 200-240 VAC, 1.25 A max. per PSU, 50/60 Hz
DC Input: -48 to -60 VDC, 5.0 A max. per PSU
ExtremeSwitching Hardware Installation Guide
Fan and Acoustic Noise
Declared Sound Power (at 25°C)
6.8 bels up to 25°C
7.6 bels up to 35°C
9.4 bels at 45°C (max)
6.8 bels up to 25°C
7.5 bels up to 35°C
9.2 bels at 45°C (max)
6.9 bels up to 30°C
7.1 bels up to 40°C
9.5 bels at 45°C (max)
6.9 bels up to 30°C
7.1 bels up to 40°C
9.4 bels at 45°C (max)
417
