Installing External Power Supplies
4. Connect the RPS-500p to its power source.
See

Connecting the RPS Cable and AC Power Cord to an RPS-500p

Installing an RPS-500p on a Flat Surface

Caution
Observe all ESD precautions when handling sensitive electronic equipment.
When installing the RPS-500p power supply on a flat surface, we recommend installing the rubber feet
to prevent the power supply from sliding.
To prepare the RPS-500p for use on a flat surface, follow these steps.
1. On a sturdy flat surface, lay the power supply on its top.
2. Remove the four rubber feet from their plastic bag in the shipping box.
3. Remove the protective strip from the back of one rubber foot and position it on a bottom corner of
the power supply.
Press the rubber foot firmly into place.
Repeat this step for each of the remaining three rubber feet.
4. After installing the rubber feet, return the power supply to its upright position.
5. Connect the RPS-500p to its power source.
See Connecting the RPS Cable and AC Power Cord to an RPS-500p
Connecting the RPS Cable and AC Power Cord to an RPS-500p
Important
When performing this task, observe all of the precautions listen in
Installing Power Supplies
Connect the RPS-500p power supply to the PoE-compliant switch using the supplied RPS cable, as
follows.
Caution
Observe all ESD precautions when handling sensitive electronic equipment.
1. Connect one end of the RPS cable to the Redundant Power Supply connector at the rear of the
power supply.
2. Connect the other end of the RPS cable to the Redundant Power Supply connector on the switch.
See Figure
on page 263.
221.
Installing an RPS-500p on a Flat Surface
on page 279.
on page 279.
ExtremeSwitching Hardware Installation Guide 279
