ExtremeSwitching 2000 W AC Power Supply

ExtremeSwitching 2000 W AC Power Supply
The ExtremeSwtiching 2000 W AC power supply is available in model XN-ACPWR-2000W-F with
front-to-back ventilation airflow:
Note
In order to obtain 2000W output from this power supply, the PSU must be connected to a
200-240VAC source.
This power supply is compatible with all X465 PoE (X465-48P, X465-48W, X465-24MU,
X465-24MU-24W, X465-24W, X465i-48W) switch models that have the same airflow direction as the
power supply.
The ExtremeSwitching 2000 W AC power supply has a keyed power inlet (C16) that requires a notched
(C15) power cord.
The ExtremeSwitching 2000 W AC power supply has the status LEDs listed in
Table 58: ExtremeSwitching 2000 W AC Power Supply LED Status Indications
IN_OK
(Green)
Off
On
On
On

Displaying the Status of Installed Power Supplies

Using the show power command, you can view detailed information about the power supplies your
switch is using. This status information may be useful for your technical support representative if you
have a network problem.
The switch collects the following power supply information:
•
The current state of the power supply (powered off or powered on).
•
Whether the unit is an internal or external power supply.
•
Power input, output, and usage statistics.
•
Airflow direction (for internal power supplies).
•
Additional details for switches in stacked configurations.
For more information, see the
138 ExtremeSwitching Hardware Installation Guide
OUT_OK Description
(Green or Red)
Off No AC input power connection or low AC voltage.
Off AC input good, 54V output disabled.
(Red) On AC input good, output (54V) fault.
(Green) On AC input good, DC outputs in spec.
ExtremeXOS 30.7 Command Reference
Power Supplies for Use with Your Switch
Guide.
