6. Lift UIC straight up until clear of locator pin
(refer to 1 in Figure 9‐10).
locator pin
Figure 9‐10: Lift or Lower UIC Over Locator Pin
7. Angle UIC upward from rear (refer to 2 in
Figure 9‐10) to expose UIC connectors to A
and B CU harnesses. While pressing
connector locking tabs, gently remove
connectors to disconnect. Do not strain
harnesses. See Figure 9‐11.
B harness
locator pin
REAR VIEW
Figure 9‐11: Disconnect or Connect A and B Harnesses
8. Lift off UIC and place in ESD bag or on clean
ESD work surface.
9‐10
To install UIC:
1. Make sure Segway PT is powered off and
2.
If harness wires are pinched or exhibit insulation
damage or the connector is damaged so as to
prevent positive locking upon installation, the
harness must be replaced.
3. Orient UIC in console housing. Make sure
4. To avoid crushing steering sensor harnesses,
5. Be sure retention putty is installed and
UIC
A harness 6. Connect (2) CU harness connectors to front
7. Orient hole in UIC over locator pin (refer to
console
Segway® Personal Transporter i2, x2, x2 Turf Parts Replacement
unplugged.
Inspect harnesses for damage to insulation or
kinks. Ensure connector locking mechanism is
intact.
CU harnesses are properly positioned in
plastic guide clips to prevent crushing of
harnesses.
make sure harnesses are properly
positioned in channel around UIC mounting
bosses. See Figure 9‐12.
keeps harness seated correctly around
bosses.
of UIC.
1 in Figure 9‐10) and lower UIC into console
housing, taking care to fold harnesses into
void without pinching.
Figure 9‐12: Position Harnesses in Channel
