Segway
Golf Bag Carrier Instructions for Installation and Operation
IF YOU PURCHASED YOUR SEGWAY HT i SERIES OR SEGWAY GT WITH THE GOLF
BAG CARRIER INSTALLED, YOU SHOULD STILL READ THE OPERATING
INSTRUCTIONS ON PAGES 6 AND 7.
This Golf Bag Carrier is to be used with the Segway HT i Series and Segway GT models. It should not be
installed on any other model.
BEFORE INSTALLING THE GOLF BAG CARRIER, YOU SHOULD FIRST LEARN TO RIDE THE
SEGWAY HT OR SEGWAY GT AS DESCRIBED IN THE RIDERS' GUIDE AND SAFETY VIDEO.
YOU REDUCE THE RISK OF INJURY BY FIRST LEARNING TO RIDE WITHOUT THE GOLF
BAG CARRIER INSTALLED. IF YOU DO NOT HAVE THE RIDERS' GUIDE AND SAFETY
VIDEO, CONTACT AN AUTHORIZED SEGWAY DEALER.
Questions?
If you have any questions or are missing a part, please contact an Authorized Segway Dealer. For
a list of Dealers, visit www.segway.com. Check www.segway.com for updates to these
instructions. Thank you.
WARNING!
Always shut down your Segway HT and unplug the Power Cord before performing any
maintenance or installing any part or accessory.
Follow these instructions carefully. Failure to follow these instructions could damage your Segway
HT and render it unsafe to use.
LIMITED WARRANTY
The Segway Golf Bag Carrier is an "Accessory" or "Replacement Part" covered for 90 days under the Segway
Human Transporter Limited Warranty (copy delivered with the kit.)
©2005 Segway LLC
®
Golf Transporter (GT)
Page 1 of 7
Contents
>
(1) Frame
>
(1) Golf Bag Holder
>
(2) Supports
>
(2) Caps
>
(6) 18mm hex fasteners
>
(4) 35mm hex fasteners with washers
>
(1) 4mm hex wrench
Tools Required
>
4mm hex wrench
>
5mm hex wrench
>
Flathead Screwdriver (not required when
purchasing Segway GT)
®
18592-00001 ac
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Segway Golf Transporter
Summary of Contents for Segway Golf Transporter
- Page 1 BAG CARRIER INSTALLED, YOU SHOULD STILL READ THE OPERATING INSTRUCTIONS ON PAGES 6 AND 7. This Golf Bag Carrier is to be used with the Segway HT i Series and Segway GT models. It should not be installed on any other model.
- Page 2 (This step is necessary only if the Golf Bag Carrier was purchased as a separate accessory. This step is not necessary on the Segway GT, as the Gearbox Plugs are not installed.) Step 2 In this step you will assemble one Support and Cap onto the Frame prior to attaching it to the Gearbox: a.
- Page 3 Golf Bag Carrier Instructions for Installation and Operation Step 3 Set the assembled parts on the Segway HT so that the Warning Label is in front of the Control Shaft and on the right side. Align the three holes in the bottom of the Support with the three threaded inserts in the Gearbox.
- Page 4 Frame, and the other tube fitting is aligned with the rear opening. (It may help to tip the Segway HT onto the left Wheel.) b. Insert the two Golf Bag Holder tube fittings into rear the two Frame openings.
- Page 5 Golf Bag Carrier Instructions for Installation and Operation To install your own golf bag Step 1 Tip the Segway HT back until it rests on the bottom of the Golf Bag Holder. Step 2 Place your golf bag into the two cradles.,...
- Page 6 Bag Carrier will not interfere with proper stepping off, but it will interfere with emergency dismounts to the front or side. You must ride with extra care to avoid any slip, trip, or tip of the Segway HT (as described in the Riders’ Guide and Safety Video).
- Page 7 Step on normally as described in the Riders’ Guide and Safety Video. You’re off to the next shot! Segway HT i167 and i170 models have an automatic shutdown feature, so that the Segway HT, if left in Power Assist Mode for approximately one minute, would power off. If you are attaching this Golf Bag Carrier to one of those i Series models, you have two options: (1) use the Keys that came with your Segway HT and re-start the Segway HT if it automatically shuts down while you are playing your shot;...
