3. Battery Packs

This chapter describes removal and installation procedures for
the Li‐ion batteries used on a Gen 2 Segway PT. For
information on using the batteries, including charging and
maintaining them, safety rules, specifications, and general
care, refer to Segway PT i2, x2 Reference Manual.
The following warnings apply to the instructions in this
Section 3 regarding Battery Packs:
Read all
instructions.
Failure to do so Failure to follow
could result in these instructions
serious injury or could lead to
death. electrical shock,
serious injury, death,
or damage to
property.
FASTENERS
Use only Segway-approved fasteners.
•
Do not tighten or reuse any fastener except the screws used to
•
attach the battery packs, wheel nuts, and LeanSteer frame.
Instead, when any other fastener is loose or removed, replace
the fastener with a new Segway-approved fastener. See
Appendix C, "Fasteners"
Do not attempt to repair any stripped or damaged screw hole.
•
Instead, replace the part. If replacement part is not available,
do not reassemble.
Insert fasteners slowly and carefully. Do not cross-thread or
•
over-tighten fasteners. Tighten only to the prescribed torque.
Failure to adhere to these warnings could lead to serious injury
•
or death or damage to property.
Segway® Personal Transporter i2, x2, x2 Turf Parts Replacement Guide
Unplug the
Power off
the Segway PT. Segway PT.
Failure to follow
these instructions
could lead to
electrical shock,
serious injury, death,
or damage to
property.
for more information.
Applies to Models
i2, x2, x2 Turf
Qualifications
Customer Replaceable
Customer Replaceable Kit
Battery Kit (20878‐00001)
(1) Li‐ion Battery
(4) Fasteners, M4 x 0.7 x 30
Required Tools
•
Torque wrench, 3mm drive
•
Hex wrench, 3mm
3‐1
