Figure 1‐1 shows the components of the
LeanSteer frame.
Q
D
G
I
H
J
E
K
L
Figure 1‐1: LeanSteer Frame Components
Wedge, Threaded Side
A
Outer Bar Clamp
B
Grip Trim
C
D Upper LeanSteer Frame
Lower LeanSteer Frame
E
Handlebar Hub Trim
F
Height Adjustment Knob
G
H M4 Threaded Rod
Washer
I
Height Adjustment Wedge
J
Wedge, Counterbore Side
K
L Fastener, SHCS, M6 x 1.0 x 45, Hex
M Slide, Top, Spacer
Upper Handlebar Stop
N
Fastener, SHCS, M4x20
O
Handlebar Tube
P
Q InfoKey and InfoKey Dock

When to Replace

You need to replace the LeanSteer frame if any
part is bent or otherwise broken. Typically, you
can replace one of its components.
Segway® Personal Transporter i2, x2, x2 Turf Parts Replacement Guide
P
C
B
O
M
N
A
F
1‐3
