Gearbox - Segway Personal Transporter i2 Parts Replacement Manual

8. Gearbox

This chapter describes troubleshooting, removal, and
installation of a gearbox assembly on a Gen 2 Segway PT. Note
that the Segway PT has two gearboxes.
The following warnings apply to the instructions in this
Section 8 regarding the Gearbox:
Read all
instructions.
Failure to do so Failure to follow
could result in these instructions
serious injury or could lead to
death. electrical shock,
serious injury, death,
or damage to
property.
Failure to follow these instructions could
cause personal injury.
Finger or
hand hazard.
Segway® Personal Transporter i2, x2, x2 Turf Parts Replacement Guide
Unplug the
Power off
the Segway PT. Segway PT.
Failure to follow
these instructions
could lead to
electrical shock,
serious injury, death,
or damage to
property.
Applies to Models
i2, x2, x2 Turf
Qualifications
Certified Service Technician
Required Tools
•
Ratchet, 3/8" drive
•
Torque wrench, 3/8" drive
•
Socket wrench, 13mm, 3/8" drive
•
T‐20 6‐lobe wrench (Model i2)
•
T‐45 6‐lobe socket wrench, 3/8" drive
•
Socket extension, 3‐in. 3/8" drive
•
Hex wrench, 4mm
•
Hex wrench, 5mm
•
Rubber mallet
•
Scraper (to remove RTV silicone sealant)
•
Razor blade
8‐1
