10. Chassis Cover

This chapter describes removal and installation procedures for
the chassis cover on a Gen 2 Segway PT.
The following warnings apply to instructions in this Section 10
regarding the Chassis Cover:
Read all
instructions.
Failure to do so Failure to follow
could result in these instructions
serious injury or could lead to
death. electrical shock,
serious injury, death,
or damage to
property.
ESD PROCEDURES
Any time repair involves opening the console or chassis cover, best-
practice electrostatic discharge (ESD) control procedures must be
followed. Failure to follow ESD procedures could result in personal
injury or damage to property.
Segway® Personal Transporter i2, x2, x2 Turf Parts Replacement Guide
Unplug the
Power off
the Segway PT. Segway PT.
Failure to follow
these instructions
could lead to
electrical shock,
serious injury, death,
or damage to
property.
Applies to Models
i2, x2, x2 Turf
Qualifications
Certified Service Technician
Technician Replaceable Parts
Chassis Cover (20316‐00001)
Chassis cover, i2 with warning label (no
fasteners included)
20540‐00001
Chassis Cover Fastener (
(12) Chassis fasteners
Required Tools
•
T‐27 6‐lobe wrench
)
10‐1
