Balance Sensor Assembly - Segway Personal Transporter i2 Parts Replacement Manual

12. Balance Sensor Assembly

This chapter describes removal and installation procedures for
the balance sensor assembly (BSA) on a Gen 2 Segway PT.
The following warnings apply to instructions in this Section 12
regarding the Balance Sensor Assembly:
Read all
instructions.
Failure to do so Failure to follow
could result in these instructions
serious injury or could lead to
death. electrical shock,
serious injury, death,
or damage to
property.
Remove
battery packs.
Failure to do so
could result in
serious injury or
death or damage to
property.
Segway® Personal Transporter i2, x2, x2 Turf Parts Replacement Guide
Unplug the
Power off
the Segway PT. Segway PT.
Failure to follow
these instructions
could lead to
electrical shock,
serious injury, death,
or damage to
property.
Applies to Models
i2, x2, x2 Turf
Qualifications
Certified Service Technician
Technician Replaceable Parts
Balance Sensor Assembly (19457‐00002)
Fasteners not included
Balance Sensor Assembly Fastener
(20566‐00001)
(4) Fasteners, pan‐head, self‐tapping,
x x
M3 0.5 12
Required Tools
•
T‐10 torque wrench
•
T‐10 6‐lobe wrench
12‐1
