Segway Personal Transporter i2 Parts Replacement Manual page 117

Callouts in the following table refer to Figure 1‐1.
Table B-4: LeanSteer Frame Parts by Model and Color
Callout Description
Wedge, threaded side
A
Outer bar clamp
B
Grip trim
C
D Upper LeanSteer frame
Lower LeanSteer frame
E
F Handlebar hub trim
Height adjustment knob
G
M4 threaded rod
H
Washer
I
Height adjustment wedge
J
K Wedge, counterbore side
Fastener, SHCS, M6x1.0x45, Hex
L
M Slide, top, spacer
Upper handlebar stop
N
Fastener, SHCS, M4x20
O
Handlebar tube
P
Segway® Personal Transporter i2, x2, x2 Turf Parts Replacement Guide
i2 White i2 Black
21069‐00001 21069‐00001
20046‐00002 20046‐00001
18892‐00001 18892‐00001
20048‐00002 20048‐00001
20529‐00002 20529‐00001
20358‐00001 20358‐00001
20750‐00001 20750‐00001
20752‐00001 20752‐00001
20751‐00001 20751‐00001
20042‐00001 20042‐00001
21067‐00001 21067‐00001
20631‐00001 20631‐00001
20040‐00001 20040‐00001
20041‐00001 20041‐00001
20306‐00001 20306‐00001
20045‐00001 20045‐00001
i2 Sage x2
21069‐00001 21069‐00001
20046‐00004 20046‐00003
18892‐00001 18892‐00001
20048‐00004 20048‐00003
20529‐00003 20491‐00000
20358‐00001 20358‐00001
20750‐00001 20750‐00001
20752‐00001 20752‐00001
20751‐00001 20751‐00001
20042‐00001 20042‐00001
21067‐00001 21067‐00001
20631‐00001 20631‐00001
20040‐00001 20040‐00001
20041‐00001 20041‐00001
20306‐00001 20306‐00001
20045‐00001 20045‐00001
B‐5
