Table D‐2: Equipment List
TOOL
Multi‐meter
Mallet
Ratchet
Blade (razor or utility knife)
Six‐lobe bits
Six‐lobe wrenches
Socket extension
Socket
Tire pump
Tire iron (qty 2)
Trigger‐style bar clamp
Torque wrenches
UIC cover extraction tool
D-2
DESCRIPTION
Capable of measuring both voltage and resistance as called out in Segway PT
i2, x2 Diagnostics Guide
Plastic or rubber, 20 oz. or 24 oz.
3/8" drive
For removal of room temperature vulcanizing (RTV) silicone sealant (not all
models)
Recommend (2) each of the following sizes: T‐20, T‐45
T‐10, T‐20, T‐25, T‐27, T‐30, T‐45
3‐in. 3/8" drive
Hex, 13mm; 6‐point is preferred
Air pump with Schrader valve attachment
Approximately 14ʺ long, motorcycle type
12" bar‐clamp (measured by the maximum opening)
Adapter to fit the following hex and 6‐lobe bits:
3/8" drive torque limiting ratchet (40‐50 N‐m minimum range)
¼" drive torque limiting ratchet (5‐13.5 N‐m minimum range)
¼" drive torque limiting screwdriver (0.3‐1.6 N‐m minimum range)
Specially designed tool for removing UIC cover without damaging brass
inserts. Order from Segway (part number 21813‐00001).
