D. Recommended Tools and Diagnostic Equipment
Table D‐2 lists and briefly describes required tools and equipment that you should have on hand prior to
servicing the Gen 2 Segway PT.
FASTENERS
Use only Segway-approved fasteners.
•
Do not tighten or reuse any fastener except the screws used to attach the battery packs, wheel nuts, and
•
LeanSteer frame. Instead, when any other fastener is loose or removed, replace the fastener with a new
Segway-approved fastener. See Appendix C,
Before using a fastener, make certain the fastener is the correct size and type with any necessary washer
•
and thread lock in place (see
Since the pre-applied thread lock compound is intended for single use only, reuse of fasteners is not
•
permitted with the exception of the wheel nuts, battery fasteners, and LeanSteer clamp bolt.
Do not attempt to repair any stripped or damaged screw hole. Instead, replace the part. If replacement
•
part is not available, do not reassemble.
Insert fasteners slowly and carefully. Do not cross-thread or over-tighten fasteners. Tighten only to the
•
prescribed torque.
Failure to adhere to these warnings could lead to serious injury or death or damage to property.
•
Table D‐2: Equipment List
TOOL
Low pressure inflation gauge
Alcohol wipes
Cotton swabs
Caulking gun
ESD equipment
Small flathead screwdriver
Hex bits
Hex wrenches
1/4" square to 1/4" hex adapter
Loctite 127864XB RTV sealant
Loctite 20‐gauge taper tip
Segway® PT i2, x2, x2 Turf Parts Replacement Guide
"Fasteners"
Table C-1 on page C-1).
DESCRIPTION
Field electrostatic discharge (ESD) kit includes static mat, wrist strap, line with
gator clip, and ground lead. Correct grounding of mat and wrist strap is
essential.
2.5mm, 3mm, 4mm, 5mm, 8mm
2.5mm, 3mm, 4mm, 5mm, 8mm
ensures water‐tight seal between console housing and cover
One tube;
Needed to apply RTV sealant
for more information.
D‐1
