Wireless InfoKey™ Controller Removal and Installation
To remove Wireless InfoKey controller:
1. Press release tab at bottom of InfoKey
Controller dock adapter. See 1 in Figure 1‐
10.
2. Slide Wireless InfoKey Controller out of
Wireless InfoKey controller dock adapter.
See 2 in Figure 1‐10.
InfoKey Dock
20946-00001
Figure 1‐10: Remove Wireless InfoKey Controller
Segway® Personal Transporter i2, x2, x2 Turf Parts Replacement Guide
To install Wireless InfoKey controller:
1. Make sure InfoKey Controller dock is
installed (page 1‐8).
2. Place Wireless InfoKey controller onto dock
adapter and slide into place until release tab
(1 in Figure 1‐10) is engaged.
3. Perform post‐service tests (page A‐1).
InfoKey
21064
1‐7
