11. CU Board

This chapter describes troubleshooting, removal, and
installation procedures for the control unit (CU) boards on a
Gen 2 Segway PT.
The following warnings apply to instructions in this Section 11
regarding the CU Board:
Read all
instructions.
Failure to do so Failure to follow
could result in these instructions
serious injury or could lead to
death. electrical shock,
serious injury, death,
or damage to
property.
Remove
battery packs.
Failure to do so
could result in
serious injury or
death or damage to
property.
Segway® Personal Transporter i2, x2, x2 Turf Parts Replacement Guide
Unplug the
Power off
the Segway PT. Segway PT.
Failure to follow
these instructions
could lead to
electrical shock,
serious injury, death,
or damage to
property.
Applies to Models
i2, x2, x2 Turf
Qualifications
Certified Service Technician
Technician Replaceable Parts
CU Board (20807‐00001)
Gen 2 controller board
Required Tools
•
T‐10 torque wrench
•
T‐10 6‐lobe wrench
•
Small flathead screwdriver
11‐1
