Console - Segway Personal Transporter i2 Parts Replacement Manual

9. Console

This chapter describes removal and installation procedures for
the console and related components on a Gen 2 Segway PT.
The following warnings apply to instructions in this Section 9
regarding the Console:
Read all
instructions.
Failure to do so Failure to follow
could result in these instructions
serious injury or could lead to
death. electrical shock,
serious injury, death,
or damage to
property.
Failure to follow these instructions could
cause personal injury.
Finger or
hand hazard.
Segway® Personal Transporter i2, x2, x2 Turf Parts Replacement Guide
Unplug the
Power off
the Segway PT. Segway PT.
Failure to follow
these instructions
could lead to
electrical shock,
serious injury, death,
or damage to
property.
Applies to Models
i2, x2, x2 Turf
Qualifications
Certified Service Technician
Required Tools
•
Torque wrench, 5mm drive
•
T‐20 6‐lobe wrench
•
T‐25 6‐lobe wrench
•
T‐27 6‐lobe wrench
•
T‐30 6‐lobe wrench
•
Hex wrench, 2mm
•
Hex wrench, 2.5mm
•
Hex wrench, 3mm
•
Hex wrench, 5mm
•
Loctite 20‐gauge taper tip
•
Tube of Loctite 127864XB RTV sealant
•
Caulking gun
•
UIC cover extraction tool
9‐1
