Power Base Trim - Segway Personal Transporter i2 Parts Replacement Manual

6. Power Base Trim

This chapter describes removal and installation procedures for
the power base trim (fascias and gearbox trim cover) on a Gen
2 Segway PT. Each Segway PT has front and rear fascia.
The following warnings apply to the instructions in this
Section 6 regarding Power Base Trim:
Read all
instructions.
Failure to do so Failure to follow
could result in these instructions
serious injury or could lead to
death. electrical shock,
serious injury, death,
or damage to
property.
Failure to follow these instructions could
cause personal injury.
Finger or
hand hazard.
Segway® Personal Transporter i2, x2, x2 Turf Parts Replacement Guide
Unplug the
Power off
the Segway PT. Segway PT.
Failure to follow
these instructions
could lead to
electrical shock,
serious injury, death,
or damage to
property.
Applies to Models
i2, x2, x2 Turf
Qualifications
Customer Replaceable
Customer Replaceable Kits
i2/x2 Power Base Front Trim (Fascia) Kit
(20947‐00001)
(1) Front fascia
Without Parking Stand:
(4) Fasteners, 10mm
With Parking Stand Mounted:
(2) Outer fasteners, 10mm
(2) Center fasteners, 14mm
i2/x2 Power Base Rear Trim (Fascia) Kit
(20948‐00001)
(1) Rear fascia
(4) Fasteners, 10mm
Console Cover Trim Kit, v1
(20951‐00001 Black • 20951‐00002 White)
(1) Console cover
Console Cover Trim Kit, v2
(21281‐00001 Black • 21281‐00002 White•
21281‐00005 Metallic Sage)
(1) Console cover
i2/x2 Gearbox Trim Cover Kit (20944‐00001)
(1) Gearbox trim cover
(3) 20553‐00001 fasteners
Technician Replaceable Parts
, v1
Console Trim
(20723‐00001 Black • 20723‐00002 White)
, v2
Console Trim
(20934‐00001 Black • 20934‐00002 White•
20934‐00003 Metallic Sage)
Required Tools
•
Hex wrench, 4mm
•
Torque wrench, 4mm drive
6‐1
