Disassembling and Reassembling Chassis Components

To disassemble chassis components:
Remove components from damaged chassis by
following procedures for individual Segway PT
components:
1. Make sure Segway PT is powered off and
unplugged.
2. Establish a serviceable power base
(page 7‐1).
3. Remove gearbox (qty 2) (page 8‐4).
4. Remove pivot base assembly (page 9‐14).
5. Remove chassis cover (page 10‐3).
6. Remove CU board (qty 2) (page 11‐3).
7. Remove balance sensor assembly
(page 12‐3).
8. Remove motor (qty 2) (page 13‐3).
14‐4
To reassemble chassis components:
Install components onto replacement chassis by
following procedures for individual Segway PT
components:
1. Make sure Segway PT is powered off and
unplugged.
2. Install motor (qty 2) (page 13‐4).
3. Install balance sensor assembly
(page 12‐3). Use self‐tapping fasteners.
4. Install CU board (qty 2) (page 11‐5). Use self‐
tapping fasteners.
5. Install chassis cover (page 10‐3).
6. Install pivot base assembly (page 9‐15).
7. Install gearbox (qty 2) (page 8‐5).
