N N o o t t e e - - You cannot remove the four floor plate bolts as they are self contained within P P e e r r f f o o r r m m a a n n c c e e - - L L O O A A D D .

5. Carefully remove the fastener assembly from the floor plate assembly.

6. If equipped with inductive charging, disconnect the red wire from the red wire and the black wire from the black wire to

disconnect the fastener assembly from the anchor-to-vehicle cable.

To reinstall, see Installing Performance-LOAD (page 19).

C C h h e e c c k k i i n n g g t t h h e e b b a a t t t t e e r r y y p p o o w w e e r r l l e e v v e e l l

Use the cot battery LED indicator to check the S S M M R R T T Pak power level. A charged S S M M R R T T Pak, in working condition,

provides up to 25 calls with a 250 pound patient (actual results may vary). The 24 VDC P P o o w w e e r r - - P P R R O O system and the S S M M R R T T

Pak is rated for 2.4 amp-hours of electric energy.

W W A A R R N N I I N N G G - - Do not remove the battery when the cot is active.

C C A A U U T T I I O O N N - - Always charge the battery before you place the product into service. An uncharged or depleted battery may

cause poor product performance.

To check the battery power level, press the retract (-) button on the cot control switch to activate the cot battery LED

indicator. The cot battery LED indicator is located at the foot end control enclosure (shown as a battery symbol).

•

The LED is solid green when the battery has a full charge or has an adequate battery power charge.

N N o o t t e e - - For best results, use the S S M M R R T T Pak until the cot battery LED indicator changes from solid green to flashing

amber.

•

The LED flashes amber when you need to charge or replace the battery

N N o o t t e e - - The cot battery LED indicator does not have to flash amber before you remove and replace the S S M M R R T T Pak,

however, this is considered to be a best practice. You can remove and recharge the S S M M R R T T Pak at any time.

•

The LED is a solid amber to indicate a battery error.

N N o o t t e e

• Only use Stryker approved batteries.

• If equipped, the powered cot fastener automatically charges the S S M M R R T T Pak battery. Automatic charging occurs when

you lock the cot into the powered cot fastener (no cable or connectors required). The cot battery LED indicator flashes

green for a moment to signify that it is charging.

• Automatic charging will only occur with S S M M R R T T Pak batteries.

U U s s i i n n g g a a n n o o n n - - u u p p g g r r a a d d e e d d X X - - f f r r a a m m e e c c o o t t f f o o r r a a m m a a s s s s c c a a s s u u a a l l t t y y i i n n c c i i d d e e n n t t

You can use some non-compatible cots, including most X-frame cots, in a mass casualty incident when equipped with the

mass casualty option for P P e e r r f f o o r r m m a a n n c c e e - - L L O O A A D D and a manual Stryker cot fastener.

The loading and unloading operations are the same as the instructions for manual loading and unloading of a cot.

U U n n l l o o a a d d i i n n g g a a c c o o m m p p a a t t i i b b l l e e c c o o t t f f r r o o m m P P e e r r f f o o r r m m a a n n c c e e - - L L O O A A D D

W W A A R R N N I I N N G G

• Always load or unload an occupied cot into a vehicle with a minimum of two trained operators.

• Always be ready to support the entire weight of the cot and patient when you unload a cot from the vehicle patient

compartment.

• Always check for sheets, restraints, or debris that may catch in the cot transport wheels or load wheels.
