Texas Instruments TMS320C6000 Series Reference Manual page 144

Instruction Type
Pipeline
Delay Slots
Example 1
Example 2
Single-cycle
Pipeline
E1
Stage
Read src2
dst
Written
Unit in use .L
0
NORM .L1 A1,A2
Before instruction
A1 02A3 469Fh
A2 XXXX XXXXh
NORM .L1 A1,A2
Before instruction
A1 FFFF F25Ah
A2 XXXX XXXXh
A1 02A3 469Fh
A2 0000 0005h
A1 FFFF F25Ah
A2 0000 0013h
TMS320C62x/C67x Fixed-Point Instruction Set
Normalize Integer
1 cycle after instruction
5
1 cycle after instruction
19
NORM
3-97
