TMS320C6745, TMS320C6747 Fixed- and Floating-Point Digital Signal Processor

1 TMS320C6745, TMS320C6747 Fixed- and Floating-Point Digital Signal Processor
1.1

Features

1
• Software Support
– TI DSP/BIOS™
– Chip Support Library and DSP Library
• 375- and 456-MHz TMS320C674x VLIW DSP
• C674x Instruction Set Features
– Superset of the C67x+ and C64x+ ISAs
– Up to 3648 MIPS and 2736 MFLOPS C674x
– Byte-Addressable (8-, 16-, 32-, and 64-Bit Data)
– 8-Bit Overflow Protection
– Bit-Field Extract, Set, Clear
– Normalization, Saturation, Bit-Counting
– Compact 16-Bit Instructions
• C674x Two-Level Cache Memory Architecture
– 32KB of L1P Program RAM/Cache
– 32KB of L1D Data RAM/Cache
– 256KB of L2 Unified Mapped RAM/Cache
– Flexible RAM/Cache Partition (L1 and L2)
• Enhanced Direct Memory Access Controller 3
(EDMA3):
– 2 Transfer Controllers
– 32 Independent DMA Channels
– 8 Quick DMA Channels
– Programmable Transfer Burst Size
• TMS320C674x Fixed- and Floating-Point VLIW
DSP Core
– Load-Store Architecture with Nonaligned
Support
– 64 General-Purpose Registers (32-Bit)
– Six ALU (32- and 40-Bit) Functional Units
– Supports 32-Bit Integer, SP (IEEE Single
Precision/32-Bit) and DP (IEEE Double
Precision/64-Bit) Floating Point
– Supports up to Four SP Additions Per Clock,
Four DP Additions Every 2 Clocks
– Supports up to Two Floating-Point (SP or DP)
Reciprocal Approximation (RCPxP) and
Square-Root Reciprocal Approximation
(RSQRxP) Operations Per Cycle
– Two Multiply Functional Units
– Mixed-Precision IEEE Floating Point Multiply
Supported up to:
– 2 SP x SP -> SP Per Clock
– 2 SP x SP -> DP Every Two Clocks
– 2 SP x DP -> DP Every Three Clocks
– 2 DP x DP -> DP Every Four Clocks
– Fixed-Point Multiply Supports Two 32 x 32-Bit
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
Order
Product
Technical
Folder Now
Documents
Support &
Tools &
Community
Software
TMS320C6745, TMS320C6747
SPRS377F – SEPTEMBER 2008 – REVISED JUNE 2014
Multiplies, Four 16 x 16-Bit Multiplies, or
Eight 8 x 8-Bit Multiplies per Clock Cycle, and
Complex Multiples
– Instruction Packing Reduces Code Size
– All Instructions Conditional
– Hardware Support for Modulo Loop
Operation
– Protected Mode Operation
– Exceptions Support for Error Detection and
Program Redirection
• 128KB of RAM Shared Memory (TMS320C6747
Only)
• 3.3-V LVCMOS I/Os (Except for USB Interfaces)
• Two External Memory Interfaces:
– EMIFA
– NOR (8- or 16-Bit-Wide Data)
– NAND (8- or 16-Bit-Wide Data)
– 16-Bit SDRAM with 128-MB Address Space
(TMS320C6747 Only)
– EMIFB
– 32-Bit or 16-Bit SDRAM with 256-MB
Address Space (TMS320C6747)
– 16-Bit SDRAM with 128-MB Address Space
(TMS320C6745)
• Three Configurable 16550-Type UART Modules:
– UART0 with Modem Control Signals
– Autoflow Control Signals (CTS, RTS) on UART0
Only
– 16-Byte FIFO
– 16x or 13x Oversampling Option
• LCD Controller (TMS320C6747 Only)
• Two Serial Peripheral Interfaces (SPIs) Each with
One Chip Select
• Multimedia Card (MMC)/Secure Digital (SD) Card
Interface with Secure Data I/O (SDIO)
• Two Master and Slave Inter-Integrated Circuit (I
Bus™)
• One Host-Port Interface (HPI) with 16-Bit-Wide
Muxed Address/Data Bus for High Bandwidth
(TMS320C6747 Only)
• Programmable Real-Time Unit Subsystem
(PRUSS)
– Two Independent Programmable Realtime Unit
(PRU) Cores
– 32-Bit Load and Store RISC Architecture
– 4KB of Instruction RAM per Core
– 512 Bytes of Data RAM per Core
2
