TMS320C6670
Multicore Fixed and Floating-Point System-on-Chip
Data Manual
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
Literature Number: SPRS689D
March 2012
