Example 1
Example 2
ABS .L1 A1,A5
Before instruction
A1 8000 4E3Dh
A5 XXXX XXXXh
ABS .L1 A1,A5
Before instruction
A1 3FF6 0010h
A5 XXXX XXXXh
Integer Absolute Value With Saturation
–2147463619 A1 8000 4E3Dh
A5 7FFF B1C3h
1073086480 A1 3FF6 0010h
A5 3FF6 0010h
TMS320C62x/C67x Fixed-Point Instruction Set
1 cycle after instruction
–2147463619
2147463619
1 cycle after instruction
1073086480
1073086480
ABS
3-29
