Pipeline
Instruction Type
Delay Slots
Example
Pipeline
Stage
E1
Read
src1, src2
Written
dst
Unit in use
.L
Single-cycle
0
LMBD .L1
A1,A2,A3
Before instruction
A1 0000 0001h
A2 009E 3A81h
A3 XXXX XXXXh
A1 0000 0001h
A2 009E 3A81h
A3 0000 0008h
TMS320C62x/C67x Fixed-Point Instruction Set
Leftmost Bit Detection
1 cycle after instruction
LMBD
3-75
